Diagnostic Aids
With ignition on and engine not running, boost pressure is equal to atmospheric pressure with signal voltage being high. Comparison of this reading with a known good vehicle using the same type sensor is a good way to check accuracy of a suspect sensor. Readings should be the same plus or minus .4 volt. Very little boost can be attained by revving the engine in Neutral.
