DTC B2602: DRL Relay Control Circuit Shorted To Ground: Notes

WARNING: This page is about a different car, the 2003 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: DTC B2602 Circuit
GM1351203Courtesy of GENERAL MOTORS CORP.
