Seat Adjuster Switch Connector End View - Front Passenger Connector End View C2 (8-Way Non-Memory)

Fig 1: Seat Adjuster Switch Connector End View - Front Passenger Connector End View C2 (8-Way Non-Memory)
G01842981Courtesy of GENERAL MOTORS CORP.
