Removal Procedure

  1. Carefully use a flat-bladed tool in order to release the outside mirror switch retaining tabs from the trim panel.
  2. Remove the outside mirror switch from the trim panel.
  3. Disconnect the electrical connector from the power folding mirror switch.
    Fig 1: Removing Outside Mirror Switch From Trim Panel
    G01477680Courtesy of GENERAL MOTORS CORP.
