| 1 |
Driver airbag #2 (High) |
Center side airbag (High) |
| 2 |
Driver airbag #2 (Low) |
- |
| 3 |
Passenger airbag #2 (Low) |
- |
| 4 |
Passenger airbag #2 (High) |
Driver rear side airbag (Low) |
| 5 |
- |
Driver rear side airbag (High) |
| 6 |
- |
Passenger rear side airbag (High) |
| 7 |
- |
Passenger rear side airbag (Low) |
| 8 |
- |
Driver rear seat belt pretensioner (Low) |
| 9 |
- |
Driver rear seat belt pretensioner (High) |
| 10 |
B+ |
Passenger rear seat belt pretensioner (High) |
| 11 |
Crash output |
Passenger rear seat belt pretensioner (Low) |
| 12 |
Passenger airbag #1 (Low) |
- |
| 13 |
Passenger airbag #1 (High) |
- |
| 14 |
Knee airbag (High) |
Center side airbag (Low) |
| 15 |
Knee airbag (Low) |
Passenger buckle sensor (High) |
| 16 |
PAB OFF lamp (Telltale) |
Driver buckle sensor (High) |
| 17 |
- |
Passenger curtain airbag (Low) |
| 18 |
- |
Passenger curtain airbag (High) |
| 19 |
Driver airbag #1 (High) |
Driver curtain airbag (High) |
| 20 |
Driver airbag #1 (Low) |
Driver curtain airbag (Low) |
| 21 |
- |
Passenger front side airbag (Low) |
| 22 |
- |
Passenger front side airbag (High) |
| 23 |
- |
Drive front side airbag (High) |
| 24 |
- |
Drive front side airbag (Low) |
| 25 |
- |
- |
| 26 |
C-CAN (Low) |
- |
| 27 |
C-CAN (HIGH) |
Passenger seat belt pretensioner (Low) |
| 28 |
IGN 1 |
Passenger seat belt pretensioner (High) |
| 29 |
Driver front impact sensor (High) |
- |
| 30 |
Driver front impact sensor (Low) |
Rear center side impact sensor (High) |
| 31 |
Passenger front impact sensor (Low) |
Rear center side impact sensor (Low) |
| 32 |
Passenger front impact sensor (High) |
Passenger seat belt pretensioner (High) |
| 33 |
- |
Passenger seat belt pretensioner (Low) |
| 34 |
- |
- |
| 35 |
- |
- |
| 36 |
- |
- |
| 37 |
|
- |
| 38 |
- |
| 39 |
- |
| 40 |
Ground |
| 41 |
Driver rear pressure side impact sensor (Low) |
| 42 |
Driver rear pressure side impact sensor (High) |
| 43 |
Diver gravity side impact sensor (High) |
| 44 |
Diver gravity side impact sensor (Low) |
| 45 |
Passenger gravity side impact sensor (Low) |
| 46 |
Passenger gravity side impact sensor (High) |
| 47 |
Driver front impact sensor (High) |
| 48 |
Driver front impact sensor (Low) |
| 49 |
Passenger front impact sensor (Low) |
| 50 |
Passenger front impact sensor (High) |
| 51 |
Passenger rear side impact sensor (High) |
| 52 |
Passenger rear side impact sensor (Low) |
