Monitor Current Data

  1. Ignition "OFF"
  2. Connect GDS to Data Link Connector (DLC).
  3. Engine "ON"
  4. Monitor "A/C Pressure" and "A/C Pressure Voltage" parameter in "Current Data" with GDS.
  5. Test Condition: A/C "OFF" and A/C "ON"

    Specification:  Refer to the illustration below

G15568246Courtesy of HYUNDAI MOTOR AMERICA
