SCC: Smart Cruise Control

Courtesy of HYUNDAI MOTOR AMERICA

Information

• SCC: Smart Cruise Control
• CC: Cruise Control

1. Vehicle speed at approximately 0 - 210 km/h
2. Transmission in D or Sports mode
3. "ESP OFF" switch OFF
4. "CRUISE" switch ON (CRUISE indicator ON)
5. Parking brake OFF

1. "CRUISE" switch OFF
2. "CANCEL" switch ON
3. Brake pedal applied
4. Driver's door opened
5. Vehicle speed at more than approximately 160 km/h (99.4 mph)
6. Vehicle speed at less than approximately 10 km/h (5 mph)
7. Transmission in N or P or R
8. ESP/TCS/ABS certain period of time operating
9. An accelerator pedal applied for more than 5 min
10. ESP OFF" switch ON (ESP OFF indicator ON)
11. Parking brake applied
12. System failure (The warning indicator ON)
13. Crack, damage or wrong installation of smart cruise control unit cover (The warning indicator ON)
