ISG (Idle Stop & Go) System - 3.3L: Alternator: Specifications: Specification

• 13.5V, 150A

Item	Specification
Rated voltage	13.5V, 180A
Speed in use	0 - 18, 000 rpm
Voltage regulator	IC Regulator built in type
Default regulated voltage (V) [COM terminal]	Regulator (External mode)	10.6 - 16
	Regulator (Internal mode)	14.2 - 14.8
Pin	1

Courtesy of HYUNDAI MOTOR AMERICA
