Charging System - 2.5L: Alternator: Specifications

13.5 V 150A

Item	Specification
Form	AC power generation
Rated Voltage	13.5V150A
Motor RPM	1000 - 18000 RPM
Regulator voltage	14.2 - 14.8
Connector pin count	1
Pulley Type	OAP

Courtesy of HYUNDAI MOTOR AMERICA
