Engine Compartment Fuse Panel Identification - 1989-90: Notes
Courtesy of GENERAL MOTORS CORP.
WARNING:
Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.
