Grade Logic Control: Descending Control

When the PCM determines that the vehicle is going down a hill in the D positions, the system selects the most suitable shift schedule based on the steepness of the grade so the vehicle can run smoothly in combination with engine braking.

Fig 1: Electronic Control System Graph - Grade Logic Control (Descending Control)

Courtesy of AMERICAN HONDA MOTOR CO., INC.
