Grade Logic Control: Descending Control

WARNING: This page is about a different variant/trim than selected.

When the PCM determines that the vehicle is going down a hill in D, the system selects the most suitable shift schedule based on the steepness of the grade so the vehicle can run smoothly in combination with engine braking.

Fig 1: Grade Logic Control - Descending Control
G06950880Courtesy of AMERICAN HONDA MOTOR CO., INC.
