Circuit Protection Devices
CIRCUIT PROTECTION DEVICES LOCATION
| Component |
Location |
| Engine Compartment Junction Block |
On left front of engine compartment. See Figure. |
| Passenger Compartment Junction Block |
Behind left end of dash. See Figure. |
| Passenger Compartment Relay Box |
Behind left end of dash, on support bracket. |
