Idle Stop & Go (ISG) System: Alternator: Specifications: Specification

Item	Specification
Rated voltage	13.5V, 180A
Speed in use	1500 - 18000 RPM
Voltage regulator	IC Regulator built in type
Default regulated voltage (V) [COM terminal]	14.09 - 14.91 (-35°C)
	13.96 - 15.04 (140°C)
Pin	1
