ADAS Control Unit 2

ADAS Control Unit 2 is installed at rear side panel RH.

Courtesy of NISSAN NORTH AMERICA, INC.
Communicates with each Control Unit via CAN Communication (via ADAS Control Unit)/ITS Communication/Chassis Communication.
ADAS Control Unit controls the each System, based on ITS Communication signal, CAN Communication signal (via ADAS Control Unit), and chassis Communication signal from each Control Unit.
