Solar Sensor: Service and Repair

Removal and Installation

Removal





1. Detach the door aperture weatherstrip.





2. Remove the A pillar trim.





3. Remove the instrument panel end panel.





4. Disconnect the lower windscreen trim panel electrical connector.





5. Remove the lower windscreen trim panel.





6. Disconnect the solar sensor electrical connector.





7. Remove the solar sensor.


Installation
1. To install, reverse the removal procedure.
