Chime Inoperative With Exterior Lights On and Drivers Door Open

Test 1 - 2:






SYMPTOM
CHIME INOPERATIVE WITH EXTERIOR LAMPS ON AND DRIVER DOOR OPEN

POSSIBLE CAUSES
- Verify key-in ignition, driver's door open chime operation
- Headlamp switch output open
- MIC - chime INOP with exterior lamps on
