C332

Component ID: 66
Component : C332

Connector:
Name : C332
Color :
# of pins : 10
Gender : FEMALE




Pin Circuit Description
1 - -
2 - -
3 D54 20WT CAN B BUS (-)
4 D55 20WT/OR CAN B BUS (+)
5 - -
6 - -
7 P187 18LG/BR LEFT SEAT HEATER B(+) DRIVER
8 - -
9 - -
10 - -
