Body Code Plate

BODY CODE PLATE DESCRIPTION

The Body Code Plate is located in the engine compartment on the right headlamp mounting bracket! radiator support. There are seven lines of information on the body code plate. Lines 4, 5, 6, and 7 are not used to define service information. Information reads from left to right, starting with line 3 in the center of the plate to line 1 at the bottom of the plate.







NOTE: Paint Code may also be found on vehicle certification label on inside of driver side door jamb.
