Module-Glow Plug-Eyelet (D3913B)

Harness-Family: Battery

Color: BLACK

Gender: FEMALE

Part Number: 09446101

Part Description: Not Available

Connector No: D3913B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: Module-Glow Plug-Eyelet Connector End View
GCWD1024564Courtesy of CHRYSLER
Fig 2: Module-Glow Plug-Eyelet Component Location
GCWD1198535Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
B1 A29 RD 08F FUSED B(+) N/A
1 A29 RD 08F FUSED B(+) N/A
(1) Pins not listed are not used for this connector
