Module-Hands Free C2 (D3887B)

Harness-Family: USB_CABLE

Color: GRAY

Gender: MALE

Part Number: 13827495

Part Description: Not Available

Connector No: D3887B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 5

Fig 1: Module-Hands Free C2 Connector End View

GCWD1024718

Courtesy of CHRYSLER

Fig 2: Module-Hands Free C2 Component Location

GCWD1198813

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

X442

NA

22

UCI USB POWER

N/A

2

X445

NA

22

UCI USB DATA (-)

N/A

3

X444

NA

22

UCI USB DATA (+)

N/A

5

X443

NA

22

UCI USB GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
