Module-Heated Seats (D3846A)

Harness-Family: Seat_Left

Color: BLACK

Gender: FEMALE

Part Number: 15326931

Part Description: GT 280 CONNECTOR ASSEMBLY

Connector No: D3846A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 10

Fig 1: Module-Heated Seats Connector End View

GCWD1024643

Courtesy of CHRYSLER

Fig 2: Module-Heated Seats Component Location

GCWD1198891

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

D

P187

LG/BR

18

LEFT FRONT SEAT HEATER CONTROL

N/A

E

F937

PK/YL

16

FUSED IGNITION SWITCH OUTPUT (RUN)

N/A

F

Z960

BK/LB

16

GROUND

N/A

J

D506

WT/DG

20

LIN BUS

N/A

K

P188

LG/VT

18

RIGHT FRONT SEAT HEATER CONTROL

N/A

⁽¹⁾	Pins not listed are not used for this connector
