Module-Compass (D3865)

Harness-Family: Headliner

Color: BLACK

Gender: FEMALE

Part Number: HCMPB-04-K

Part Description: HCM 4P Female HOUSING ASSEMBLY

Connector No: D3865

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 4

Fig 1: Module-Compass Connector End View

GCWD1016881

Courtesy of CHRYSLER

Fig 2: Module-Compass Component Location

GCWD1213101

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

2

D506

WT/DG

20

LIN BUS

N/A

3

Z919

BK

20

GROUND

N/A

4

F921

PK/YL

~~

FUSED IGNITION RUN CONTROL OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
