Module-Powertrain Control C2 (3.6L) (D3838B)

Harness-Family: Powertrain

Color: BROWN

Gender: FEMALE

Part Number: 1924944-1

Part Description: Not Available

Connector No: D3838B

Option: 3.6L

Repair Kit Part Number: Not Available

Cavity Count: 96

Fig 1: Module-Powertrain Control C2 Connector End View (3.6L)
GCWD1006480Courtesy of CHRYSLER
Fig 2: Module-Powertrain Control C2 Component Location (3.6L)
GCWD1188725Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
B40 A804 RD/VT 18 GEN SENSE N/A
B67 F855 PK/YL 20 5 VOLT SUPPLY N/A
B87 F856 YL/PK 20 5 VOLT SUPPLY N/A
B16 G24 VT/BR 20 EOT SIGNAL N/A
B20 G6 VT/GY 20 OIL PRESSURE SIGNAL N/A
B93 G62 VT/YL 20 OIL PRESSURE SOL CONTROL N/A
B45 K1 VT/BR 20 MAP SIGNAL N/A
B75 K10 DB/OR 16 COIL CONTROL 6 N/A
B8 K11 BR/YL 20 INJECTOR CONTROL 1 N/A
B9 K12 BR/DB 20 INJECTOR CONTROL 2 N/A
B90 K122 BR/DG 20 TP 2 SIGNAL N/A
B3 K124 DB/GY 18 ETC MOTOR (+) N/A
B4 K126 DB/LG 18 ETC MOTOR (-) N/A
B10 K13 BR/LB 20 INJECTOR CONTROL 3 N/A
B11 K14 BR/TN 20 INJECTOR CONTROL 4 N/A
B43 K141 DB/YL 20 O2 1/2 SIGNAL N/A
B73 K15 DB/GY 16 COIL CONTROL 4 N/A
B74 K16 DB/YL 16 COIL CONTROL 5 N/A
B25 K17 DB/TN 16 COIL CONTROL 2 N/A
B49 K18 DB/OR 16 COIL CONTROL 3 N/A
B1 K19 DB/DG 16 COIL CONTROL 1 N/A
B72 K199 BR/VT 20 O2 2/1 HEATER CONTROL N/A
B12 K2 VT/OR 18 ECT SIGNAL N/A
B2 K20 BR/GY 18 GEN FIELD CONTROL N/A
B17 K21 LG/WT 20 IAT SIGNAL N/A
B89 K22 BR/OR 20 TP 1 SIGNAL N/A
B86 K24 BR/LB 20 CKP SIGNAL N/A
B13 K242 BR/WT 20 KS 2 SIGNAL N/A
B42 K243 BR 20 O2 2/2 SIGNAL N/A
B22 K276 DB/WT 20 VVT EXHAUST CONTROL N/A
B95 K277 DB/WT 20 VVT EXHAUST CONTROL 2 N/A
B48 K299 BR/WT 20 O2 1/2 HEATER CONTROL SUPPLY N/A
B79 K38 BR/OR 20 INJECTOR CONTROL 5 N/A
B96 K399 BR/GY 20 O2 2/2 HEATER CONTROL N/A
B44 K41 DB/LB 20 O2 1/1 SIGNAL N/A
B14 K42 DB/YL 20 KS 1 SIGNAL N/A
B41 K43 DB/LG 20 O2 2/1 SIGNAL N/A
B85 K44 GY/DB 20 CMP SIGNAL N/A
B62 K441 DB/BR 20 CMP SIGNAL 2 N/A
B63 K444 DB/TN 20 CMP SIGNAL 3 N/A
B61 K445 DB 20 CMP SIGNAL 4 N/A
B80 K58 BR/VT 20 INJECTOR CONTROL 6 N/A
B23 K76 BR/WT 20 VVT INTAKE CONTROL N/A
B94 K78 BR/LB 20 VVT INTAKE CONTROL 2 N/A
B66 K900 DB/DG 20 SENSOR GROUND N/A
B19 K902 BR/DG 20 O2 RETURN (UPSTREAM) N/A
B18 K904 LB/GY 20 O2 RETURN (DOWNSTREAM) N/A
B65 K922 BR/DB 20 TP SENSOR RETURN N/A
B37 K924 WT/BR 20 KS 2 RETURN N/A
B88 K925 DB/GY 20 CKP GROUND N/A
B38 K942 BR/LG 20 KS 1 RETURN N/A
B24 K99 BR/YL 20 O2 1/1 HEATER CONTROL N/A
(1) Pins not listed are not used for this connector
