Fan Module-Radiator Cooling (D3022A)

Harness-Family: Headlamp

Color: BLACK

Gender: FEMALE

Part Number: 7283-8496-30

Part Description: 2 X 1.5+ 2 X 9.5 CONNECTOR SUB ASSEMBLY

Connector No: D3022A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 4

Fig 1: Fan Module-Radiator Cooling Connector End View
GCWD1052494Courtesy of CHRYSLER
Fig 2: Fan Module-Radiator Cooling Component Location
GCWD1188767Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
A1 A924 RD 08F FUSED B(+) N/A
A4 K175 BR/LB 18 RAD FAN CONTROL N/A
A2 Z904 BK 08F GROUND N/A
(1) Pins not listed are not used for this connector
