Module-Inverter (D3920A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 1456471-1

Part Description: 8P UNSEALED HYBRID PLUG ASSEMBLY

Connector No: D3920A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 8

Fig 1: Module-Inverter Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Inverter Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P802

LG/OR

110 VOLT AC LINE 2

N/A

A904

FUSED B(+)

N/A

P801

110 VOLT AC LINE 1

N/A

P807

LG/LB

INVERTER SWITCH SIGNAL

N/A

P806

LG/WT

INVERTER STATUS INDICATOR DRIVER

N/A

Z917

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
