Module-Occupant Restraint Controller C1 (Except Export) (D3834A)

Harness-Family: IP

Color: RED

Gender: FEMALE

Part Number: 3-1438640-1

Part Description: 32P SHUNTED ORC MODULE CONNECTOR

Connector No: D3834A

Option: EXCEPT EXPORT

Repair Kit Part Number: Not Available

Cavity Count: 32

Fig 1: Module-Occupant Restraint Controller C1 Connector End View (Except Export)

Courtesy of CHRYSLER

Fig 2: Module-Occupant Restraint Controller C1 Component Location (Except Export)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

D64

WT/LB

CAN C (-)

N/A

D65

WT/BK

CAN C (+)

N/A

Z916

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
