Sensor-Input Speed (D1660)

Harness-Family: Transmission

Color: BLACK

Gender: FEMALE

Part Number: 7183-7874-30

Part Description: Not Available

Connector No: D1660

Option: Standard

Repair Kit Part Number: 68018955AA

Cavity Count:

Fig 1: Sensor-Input Speed Connector End View

GCWD1024451

Courtesy of CHRYSLER

Fig 2: Sensor-Input Speed Component Location

GCWD1131038

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

T16

YL/OR

18

TRANSMISSION CONTROL OUTPUT

N/A

2

T14

DG/BK

18

INPUT SPEED SIGNAL

N/A

3

T13

DG/TN

18

SPEED SENSOR GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
