Module-Hands Free C1 (D3887A)

Harness-Family: IP

Color: DARK GRAY

Gender: FEMALE

Part Number: 917989-6

Part Description: INSULATOR

Connector No: D3887A

Option: Standard

Repair Kit Part Number: 05083221AA

Cavity Count: 22

Fig 1: Module-Hands Free C1 Connector End View

GCWD1016904

Courtesy of CHRYSLER

Fig 2: Module-Hands Free C1 Component Location

GCWD1131153

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

A417

RD/DG

22

FUSED B(+)

N/A

4

D54

WT/PK

22

CAN B (-)

N/A

5

X722

LB/DG

22

MICROPHONE 2 IN (+)

N/A

8

X703

DG/OR

22

LEFT AUDIO OUTPUT

N/A

9

X704

DG/PK

22

RIGHT AUDIO OUTPUT

N/A

10

X795

DG

22

COMMON AUDIO OUTPUT

N/A

14

D55

WT/OR

22

CAN B (+)

N/A

16

X712

DB/WT

22

MICROPHONE 1 IN (+)

N/A

17

X792

LB/TN

22

MICROPHONE IN (-)

N/A

20

X793

DG/YL

22

MICROPHONE FEED

N/A

21

X835

OR/BK

22

SENSOR GROUND

N/A

22

Z903

BK/YL

18

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
