Module-Power-Blower Motor-Front (D6608A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 6098-1449

Part Description: 312 4 WAY CONNECTOR SUB ASSEMBLY

Connector No: D6608A

Option: Standard

Repair Kit Part Number: 68087923AA

Cavity Count: 4

Fig 1: Module-Power-Blower Motor-Front Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Power-Blower Motor-Front Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z903

BK/LB

GROUND

N/A

C56

DB/LB

BLOWER CONTROL

N/A

BLOWER MOTOR SUPPLY

N/A

Z134

BK/LG

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
