Module-Occupant Restraint Controller C2 (D3834B)

Harness-Family: BODY

Color: AQUA

Gender: FEMALE

Part Number: 2098966-1

Part Description: Not Available

Connector No: D3834B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Occupant Restraint Controller C2 Connector End View
GCWD1079579Courtesy of CHRYSLER
Fig 2: Module-Occupant Restraint Controller C2 Component Location
GCWD1078069Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
2 R47 DB 0.75 SECOND ROW LEFT SEAT SQUIB LINE 2 N/A
3 R48 DG/GY 0.75 SECOND ROW RIGHT SEAT SQUIB LINE 1 N/A
5 R78 LG 0.5 PASSENGER LOAD LIMITER LINE 1 N/A
6 R75 LB/VT 0.5 DRIVER LOAD LIMITER LINE 2 N/A
9 R8 GY/LG 0.5 RIGHT SEAT THORAX SQUIB 1 LINE 1 N/A
10 R5 LB/VT 0.5 LEFT SEAT THORAX SQUIB 1 LINE 2 N/A
11 R280 DB/TN 0.5 PASENGER SEAT BELT RETRACTOR TENSIONER LINE 1 N/A
12 R277 GY/VT 0.5 DRIVER SEAT BELT RETRACTOR TENSIONER LINE 2 N/A
13 R510 LG/DB 0.5 PASSENGER SEAT BELT ANCHOR TENSIONER LINE 1 N/A
14 R507 LG/DG 0.5 DRIVER SEAT BELT ANCHOR TENSIONER LINE 2 N/A
15 R4 OR/LB 0.5 RIGHT CURTAIN SQUIB 1 LINE 1 N/A
16 R1 LB/WT 0.5 LEFT CURTAIN SQUIB 1 LINE 2 N/A
17 R20 WT/LG 0.5 RIGHT SIDE IMPACT SENSOR 2 GROUND N/A
18 R18 LB 0.5 RIGHT SIDE IMPACT SENSOR 2 SIGNAL N/A
19 R730 LB/BK 0.5 PASSENGER SEAT DETECTION RETURN N/A
20 R71 LB/VT 0.35 LEFT REAR SEAT BELT BUCKLE SWITCH SENSE N/A
21 R72 VT/LB 0.35 RIGHT REAR SEAT BELT BUCKLE SWITCH SENSE N/A
22 R27 LB/OR 0.35 2ND ROW SEAT BELT SWITCH SENSE N/A
23 R58 LB/GY 0.5 PASSENGER SEAT BELT SWITCH SENSE N/A
24 R57 LG/GY 0.5 DRIVER SEAT BELT BUCKLE SWITCH SENSE N/A
25 R13 LG/TN 0.5 LEFT SIDE IMPACT SENSOR 1 SIGNAL N/A
26 R15 LG/BR 0.5 LEFT SIDE IMPACT SENSOR 1 GROUND N/A
27 R283 LB/DG 0.75 PASSENGER SEAT OCCUPANT DETECTION SIGNAL N/A
28 R16 BR/LG 0.5 RIGHT SIDE IMPACT SENSOR 1 GROUND N/A
29 R14 TN/LG 0.5 RIGHT SIDE IMPACT SENSOR 1 SIGNAL N/A
30 R263 LB/VT 0.5 DRIVER SEAT POSITION SENSOR VOLTAGE N/A
31 R130 LG/DB 0.5 LEFT SIDE IMPACT PRESSURE SENSOR SIGNAL N/A
32 R150 LG/PK 0.5 LEFT SIDE IMPACT PRESSURE SENSOR GROUND N/A
33 R264 VT/LB 0.5 PASSENGER SEAT POSITION SENSOR VOLTAGE N/A
34 R160 BR 0.5 RIGHT SIDE IMPACT PRESSURE SENSOR GROUND N/A
35 R140 TN 0.5 RIGHT SIDE IMPACT PRESSURE SENSOR SIGNAL N/A
36 R729 LG/BK 0.5 DRIVER SEAT DETECTION RETURN N/A
38 R49 DB/GY 0.75 SECOND ROW LEFT SEAT SQUIB LINE 1 N/A
39 R46 DG 0.75 SECOND ROW RIGHT SEAT SQUIB LINE 2 N/A
41 R76 VT/LB 0.5 PASSENGER LOAD LIMITER LINE 2 N/A
42 R77 LG/YL 0.5 DRIVER LOAD LIMITER LINE 1 N/A
45 R6 VT/LB 0.5 RIGHT SEAT THORAX SQUIB 1 LINE 2 N/A
46 R7 LG/GY 0.5 LEFT SEAT THORAX SQUIB 1 LINE 1 N/A
47 R279 GY/LB 0.5 PASSENGER SEAT BELT RETRACTOR TENSIONER LINE 2 N/A
48 R278 DB/DG 0.5 DRIVER SEAT BELT RETRACTOR TENSIONER LINE 1 N/A
49 R509 LG/DG 0.5 PASSENGER SEAT BELT ANCHOR TENSIONER LINE 2 N/A
50 R508 LB/WT 0.5 DRIVER SEAT BELT ANCHOR TENSIONER LINE 1 N/A
51 R2 WT/LB 0.5 RIGHT CURTAIN SQUIB 1 LINE 2 N/A
52 R3 LB/OR 0.5 LEFT CURTAIN SQUIB 1 LINE 1 N/A
53 R17 LG 0.5 LEFT SIDE IMPACT SENSOR 2 SIGNAL N/A
54 R19 LG/WT 0.5 LEFT SIDE IMPACT SENSOR 2 GROUND N/A
(1) Pins not listed are not used for this connector
