Module-Powertrain Control C2 (3.2L) (D3821B)

Harness-Family: ENGINE

Color: BROWN

Gender: FEMALE

Part Number: 1924943-1

Part Description: Not Available

Connector No: D3821B

Option: 3.2L

Repair Kit Part Number: Not Available

Cavity Count: 96

Fig 1: Module-Powertrain Control C2 Connector End View (3.2L)
GCWD1006480Courtesy of CHRYSLER
Fig 2: Module-Powertrain Control C2 Component Location (3.2L)
GCWD1077913Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 K19 DB/DG 1.0 COIL CONTROL 1 N/A
2 K20 BR/GY 1.0 GEN FIELD CONTROL N/A
3 K447 TN/YL 1.0 ETC MOTOR (+) N/A
4 K448 TN/OR 1.0 ETC MOTOR (-) N/A
8 K11 BR/YL 0.75 INJECTOR CONTROL 1 N/A
9 K12 BR/DB 0.75 INJECTOR CONTROL 2 N/A
10 K13 BR/LB 0.75 INJECTOR CONTROL 3 N/A
11 K14 BR/TN 0.75 INJECTOR CONTROL 4 N/A
12 K2 VT/OR 0.35 ECT SIGNAL N/A
13 K242 BR/WT 0.5 KS 2 SIGNAL N/A
14 K42 DB/YL 0.5 KS 1 SIGNAL N/A
16 G24 VT/BR 0.5 EOT SIGNAL N/A
17 K21 DB/LG 0.5 IAT SIGNAL N/A
18 K904 DB/DG 0.5 O2 RETURN (DOWNSTREAM) N/A
19 K902 BR/DG 0.5 O2 RETURN (UPSTREAM) N/A
20 G6 VT/GY 0.75 OIL PRESSURE SIGNAL N/A
22 K276 DB/WT 0.75 VVT EXHAUST CONTROL 1/2 N/A
23 K76 BR/WT 0.75 VVT INTAKE CONTROL 1/1 N/A
24 K99 BR/LG 1.0 O2 1/1 HEATER CONTROL N/A
25 K17 DB/TN 1.0 COIL CONTROL 2 N/A
37 K924 WT/BR 0.5 KS 2 RETURN N/A
38 K942 BR/LG 0.5 KS 1 RETURN N/A
40 A804 RD/VT 0.5 GEN SENSE N/A
41 K43 DB/LG 0.5 O2 2/1 SIGNAL N/A
42 K243 BR 0.5 O2 2/2 SIGNAL N/A
43 K141 DB/YL 0.5 O2 1/2 SIGNAL N/A
44 K41 DB/LB 0.5 O2 1/1 SIGNAL N/A
45 K1 VT/BR 0.5 MAP SIGNAL N/A
48 K299 BR/WT 1.0 O2 1/2 HEATER CONTROL SUPPLY N/A
49 K18 DB/OR 1.0 COIL CONTROL 3 N/A
61 K445 DB/DG 0.5 CMP SENSOR SIGNAL 2/2 N/A
62 K441 DB/BR 0.5 CMP SENSOR SIGNAL 1/2 N/A
63 K444 DB/TN 0.5 CMP SENSOR SIGNAL 2/1 N/A
65 K922 BR/DB 0.5 TP SENSOR RETURN N/A
66 K900 BK/PK 0.75 SENSOR GROUND N/A
67 F855 PK/YL 0.75 5 VOLT SUPPLY N/A
68 K915 BR/WT 0.5 SENSOR GROUND N/A
72 K199 BR/VT 1.0 O2 2/1 HEATER CONTROL N/A
73 K15 DB/GY 1.0 COIL CONTROL 4 N/A
74 K16 DB/YL 1.0 COIL CONTROL 5 N/A
75 K10 DB/OR 1.0 COIL CONTROL 6 N/A
79 K38 BR/OR 0.75 INJECTOR CONTROL 5 N/A
80 K58 BR/VT 0.75 INJECTOR CONTROL 6 N/A
83 T753 DG/YL 0.5 IGNITION CRANK SENSE N/A
85 K44 DB/GY 0.5 CMP SENSOR SIGNAL 1/1 N/A
86 K24 BR/LB 0.75 CKP SIGNAL N/A
87 F856 YL/PK 0.5 5 VOLT SUPPLY N/A
88 K925 DB/GY 0.5 CKP GROUND N/A
89 K22 BR/OR 0.5 TP 1 SIGNAL N/A
90 K122 BR/DG 0.5 TP 2 SIGNAL N/A
92 T752 DG/OR 0.75 STARTER RELAY CONTROL N/A
93 G62 VT/YL 0.75 OIL PRESSURE SOL CONTROL N/A
94 K78 TN 0.75 VVT INTAKE CONTROL 2/1 N/A
95 K277 DB 0.75 VVT EXHAUST CONTROL 2/2 N/A
96 K399 BR/GY 1.0 O2 2/2 HEATER CONTROL N/A
(1) Pins not listed are not used for this connector
