Module-Inverter (D2831A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 1456471-2

Part Description: Not Available

Connector No: D2831A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 8

Fig 1: Module-Inverter Connector End View

GCWD1079527

Courtesy of CHRYSLER

Fig 2: Module-Inverter Component Location

GCWD1078950

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

P828

LG/OR

16

220 VOLT AC LINE 2

N/A

1

P802

LG/OR

16

110 VOLT AC LINE 2

N/A

4

A401

RD/LG

2.0

FUSED B(+)

N/A

5

P824

LG

16

220 VOLT AC LINE 1

N/A

5

P801

LG

16

110 VOLT AC LINE 1

N/A

6

P825

LG/LB

0.5

INVERTER SWITCH SIGNAL

N/A

6

P805

LG/LB

0.5

110 VOLT AC LINE 3

N/A

8

Z911

BK

2.0

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
