Module-Powertrain Control C1 (D3837A)

Harness-Family: LEFT DASH

Color: BLACK

Gender: FEMALE

Part Number: 1928405063

Part Description: Not Available

Connector No: D3837A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 94

Fig 1: Module-Powertrain Control C1 Connector End View
GCWD1006535Courtesy of CHRYSLER
Fig 2: Module-Powertrain Control C1 Component Location
GCWD1079426Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 F344 BR/GY 2.0 FUSED ASD RELAY OUTPUT N/A
2 Z909 BK 2.0 GROUND N/A
3 F342 BR/WT 2.0 ASD CONTROL OUTPUT N/A
4 Z909 BK 2.0 GROUND N/A
5 F342 BR/WT 2.0 ASD CONTROL OUTPUT N/A
6 Z909 BK 2.0 GROUND N/A
7 K79 BR/LB 1.0 O2 1/1 HEATER CONTROL N/A
12 C818 VT/BR 0.35 A/C PRESSURE 5 VOLT SUPPLY N/A
14 K354 BR/LG 0.5 EXHAUST DIFFERENTIAL PRESSURE 5 VOLT SUPPLY N/A
16 K852 BR/VT 0.75 5 VOLT SUPPLY N/A
17 K854 VT/BR 0.5 5 VOLT SUPPLY N/A
18 K859 BR/DB 0.75 5 VOLT SUPPLY N/A
19 K362 BR 0.5 MASS AIR FLOW TEMP SIGNAL N/A
20 K957 BK/OR 0.5 MAF GROUND N/A
21 K157 YL 0.5 MAF SIGNAL N/A
24 D27 TN/WT 0.5 CAN C (+) N/A
25 D28 YL 0.5 CAN C (-) N/A
26 K202 DB/BR 0.5 GLOW PLUG RELAY CONTROL N/A
28 K51 BR/WT 0.75 ASD RELAY CONTROL N/A
32 G123 VT/LG 0.75 WIF SENSOR 1 SIGNAL N/A
33 K923 BR/WT 0.75 WATER IN FUEL SENSOR GROUND N/A
34 C918 BR/WT 0.35 A/C PRESSURE RETURN N/A
36 K951 BR/DB 0.5 EXHAUST DIFFERENTIAL PRESSURE SENSOR GROUND N/A
38 K167 BR/YL 0.5 APP SENSOR GROUND 1 N/A
39 K400 BR/VT 0.5 APP SENSOR GROUND 2 N/A
41 K914 BR/WT 0.75 SENSOR GROUND N/A
42 K804 BR/LG 0.75 STOP START NEUTRAL SW SIG N/A
43 T26 DG/OR 0.35 CLUTCH UPSTOP SIGNAL N/A
44 T22 YL/VT 0.5 BACKUP LAMP SWITCH SIGNAL N/A
48 K175 BR/LB 0.75 RAD FAN CONTROL N/A
49 K173 BR/VT 0.75 RADIATOR FAN CONTROL SIGNAL N/A
53 T752 DG/OR 0.75 STARTER RELAY CONTROL N/A
54 F942 PK/LG 0.75 FUSED IGNITION SWITCH OUTPUT (RUN-START) N/A
56 C18 LB/BR 0.35 A/C PRESSURE SIGNAL N/A
57 T17 DG/YL 0.5 CLUTCH SW SIG 2 N/A
58 K355 BR/DG 0.5 EXHAUST DIFFERENTIAL PRESSURE SIGNAL N/A
60 K23 BR/WT 0.5 APP SIGNAL 1 N/A
61 K29 WT/BR 0.5 APP SIGNAL 2 N/A
62 K806 DB/BR 0.75 STOP START HOOD AJAR SW SIG N/A
63 K41 DB/LB 0.5 O2 1/1 SIGNAL N/A
64 K89 BR/LG 0.5 O2 1/1 POSITIVE CURRENT CONTROL N/A
65 K159 BR/PK 0.75 FUEL TEMP SNSR RTN N/A
67 K330 LB/BR 0.5 GLOW PLUG MODULE CTRL N/A
70 N116 DB 0.5 CRANKCASE VENT HEATER CONTROL N/A
72 G62 VT/YL 0.75 OIL PRESSURE SOL CONTROL N/A
75 K31 BR 0.75 FUEL PUMP CONTROL N/A
76 T753 DG/YL 0.5 IGNITION CRANK SENSE N/A
81 K385 YL/BR 0.5 EXHAUST GAS TEMP 2 PRE N/A
82 K384 BR/YL 0.5 EXHAUST TEMPERATURE SENSOR 4 SIGNAL N/A
83 K900 BK/PK 0.75 SENSOR GROUND N/A
84 K372 BR/DG 0.5 EXHAUST TEMPERATURE 1/3 SENSOR SIGNAL N/A
85 K902 DB/DG 0.5 O2 RETURN (UPSTREAM) N/A
86 K103 BR/LB 0.5 O2 1/1 PUMP CELL CURRENT TRIM N/A
87 K156 BR/YL 0.75 FUEL TEMP SIGNAL N/A
88 B135 DG/LG 0.5 BRAKE SIGNAL 1 N/A
89 K348 BR/YL 0.5 SMART POWER RELAY RTN N/A
90 D509 WT/OR 0.5 LIN BUS N/A
92 T762 DG/YL 0.75 STOP/START ICR RELAY CONTROL N/A
93 K137 DB/OR 0.75 WASTEGATE SOL CONTROL N/A
94 C13 LB/OR 0.75 A/C CLUTCH CONTROL N/A
(1) Pins not listed are not used for this connector
