Module-Powertrain Control C2 (D3837B)

Harness-Family: Engine_Diesel

Color: BLACK

Gender: FEMALE

Part Number: 284742-1

Part Description: Not Available

Connector No: D3837B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Powertrain Control C2 Connector End View
GCWD1081607Courtesy of CHRYSLER
Fig 2: Module-Powertrain Control C2 Component Location
GCWD1078498Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 K13 BR/WT 14 INJECTOR CONTROL 3 N/A
2 K12 GY/RD 14 INJECTOR CONTROL 2 N/A
4 N117 YL/DB 20 INTAKE SWIRL SERVO MOTOR CONTROL N/A
5 K945 WT/BK 18 ACTUATOR SWIRL END POSITION RTN N/A
6 K351 VT/WT 20 5V ACTUATOR SWIRL END POSITION N/A
7 K551 WT/DB 20 5 VOLT SUPPLY N/A
9 K834 DB/WT 20 EGR 5 VOLT SUPPLY N/A
10 K668 WT/OR 20 5 VOLT SUPPLY N/A
11 K350 RD/LG 20 FUEL PRESSURE 5 VOLT SUPPLY N/A
13 K844 WT/RD 20 CMP 5 VOLT SUPPLY N/A
14 K44 GY 20 CMP SENSOR SIGNAL 1/1 N/A
15 K365 YL/BK 18 FUEL QUANTITY CONTROL N/A
16 K11 DB/RD 14 INJECTOR CONTROL 1 N/A
17 K14 RD/YL 14 INJECTOR CONTROL 4 N/A
19 K670 GY/LG 16 EGR BYPASS VALVE SIGNAL N/A
20 K312 YL/RD 16 TTVA POSITION SENSOR SIGNAL N/A
21 K22 OR 20 TP 1 SIGNAL N/A
22 K922 WT/BK 18 TP SENSOR RETURN N/A
24 K934 VT 20 EGR SENSOR GROUND N/A
25 K690 BR/VT 20 COMBO PRESS AND TEMP SNSR RTN N/A
26 K359 BK/VT 20 FUEL PRESSURE SENSOR GROUND N/A
28 K944 RD/YL 20 CMP GROUND N/A
31 K613 BR/BK 14 INJECTOR 3 CONTROL N/A
32 K611 DB 14 INJECTOR 1 CONTROL N/A
35 K684 DB/RD 18 EGR CONTROL 2 N/A
37 K552 LG/DB 20 SENSOR GROUND N/A
39 K683 DB 20 EGR SIGNAL N/A
40 K37 WT/BK 20 BOOST PRESSURE SIGNAL N/A
41 K181 YL 20 FUEL PRESSURE SIGNAL N/A
44 K925 WT/YL 18 CKP GROUND N/A
46 K612 GY/YL 14 INJECTOR 2 CONTROL N/A
48 K614 RD/BK 14 INJECTOR 4 CONTROL N/A
50 K682 GY/RD 18 EGR CONTROL 1 N/A
51 G60 DB/LG 20 OIL PRESS SENSE/SW SIG 2 N/A
53 K553 GY/BK 20 TURBO POSITION SIGNAL N/A
54 G6 GY/DB 20 OIL PRESSURE SIGNAL N/A
55 K48 WT/LG 20 AIR TEMP SENSOR SIGNAL N/A
57 K2 DB/RD 20 ECT SIGNAL N/A
58 K200 GY/LG 20 COOLANT TEMPERATURE SENSOR RETURN N/A
59 K24 GY/BK 18 CKP SIGNAL N/A
60 K366 OR/BK 18 FUEL QUANTITY SOLENOID 12 VOLT SUPPLY N/A
(1) Pins not listed are not used for this connector
