Module-Powertrain Control C2 (2.4L) (D3838B)

Harness-Family: Powertrain

Color: BROWN

Gender: FEMALE

Part Number: 0-1924944-6

Part Description: Not Available

Connector No: D3838B

Option: 2.4L

Repair Kit Part Number: Not Available

Cavity Count: 96

Fig 1: Module-Powertrain Control C2 Connector End View (2.4L)

Courtesy of CHRYSLER

Fig 2: Module-Powertrain Control C2 Component Location (2.4L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

B92

C27

LB/WT

0.50

A/C COMPRESSOR CONTROL

N/A

⁽¹⁾	Pins not listed are not used for this connector
