Switch, Power Window: Installation: Installation

Fig 1: Power Window Switch

Courtesy of CHRYSLER GROUP, LLC

1. Place the mirror switch in bolster opening and firmly snap into place.
2. Connect the electrical harness connectors.
3. Install the front door bolster. Refer to PANEL, DOOR TRIM, BOLSTER, INSTALLATION .
4. Connect the battery negative cable.
