Removal And Installation

WARNING: This page is about a different car, the 2020 RAM 2500 HD. However, it is still accessible from the selected car via links, so may be relevant.
WARNING:

To avoid serious or fatal injury on vehicles equipped with airbags, disable the Supplemental Restraint System (SRS) before attempting any steering wheel, steering column, airbags, airbag curtains, knee blocker, seat belt tensioner, impact sensor or instrument panel component diagnosis or service. Disconnect the Intelligent Battery Sensor (IBS)/negative battery cable assembly from the negative battery post, then wait two minutes for the system capacitor to discharge before performing further diagnosis or service. This is the only sure way to disable the SRS. Failure to take the proper precautions could result in accidental airbag deployment.

  1. Disconnect and isolate the negative battery cable(s). Refer to STANDARD PROCEDURE .
  2. Remove the bezel assembly from the wheel to access the back of the switches. Refer to SWITCH, EVIC CONTROL, REMOVAL AND INSTALLATION .
    GC0185948Courtesy of CHRYSLER GROUP, LLC
  3. Disconnect the wire harness connectors (1).
  4. Remove the fasteners (2) that hold the speed control switch to the bezel.
  5. Remove the speed control switch (3) from the vehicle.

INSTALLATION

WARNING:

To avoid serious or fatal injury on vehicles equipped with airbags, disable the Supplemental Restraint System (SRS) before attempting any steering wheel, steering column, airbags, airbag curtains, knee blocker, seat belt tensioner, impact sensor or instrument panel component diagnosis or service. Disconnect the Intelligent Battery Sensor (IBS)/negative battery cable assembly from the negative battery post, then wait two minutes for the system capacitor to discharge before performing further diagnosis or service. This is the only sure way to disable the SRS. Failure to take the proper precautions could result in accidental airbag deployment.

  1. Install the speed control switch in the bezel.
  2. Install the speed control switch fasteners and tighten securely.
  3. Connect the wire harness connectors.
  4. Install the bezel assembly on the steering wheel. Refer to SWITCH, EVIC CONTROL, REMOVAL AND INSTALLATION .
  5. Connect the negative battery cable(s). Refer to STANDARD PROCEDURE .
