Electronic Limited Slip Differential (ELSD) Module

WARNING: This page is about a different car, the 2021 Jeep Grand Cherokee L. However, it is still accessible from the selected car via links, so may be relevant.

REMOVAL

Remove the left rear quarter panel assembly. Refer to PANEL, QUARTER TRIM, REMOVAL AND INSTALLATION .

Courtesy of CHRYSLER GROUP, LLC

1 - Wire Harness Connectors

1 - ELSD Module Nuts

2 - Electric Limited Slip Differential (ELSD) Module

Remove the ELSD module nuts.
Remove the ELSD module from the vehicle.

INSTALLATION

Follow the removal procedure in reverse for general reassembly of the components on the vehicle. The steps listed below are calling out specific procedures that should be followed during installation.

During installation, torque the following fasteners to specification:

Electronic Limited Slip Differential (ELSD) Module Nuts

7 N-m (62 In. Lbs.)

Perform the Electronic Limited Slip Differential Module Verification Test. Refer to ELSD VERIFICATION TEST .
