Module-Integrated Center Stack Switch Bank (Standard) Connector End View (D2695A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 30700-1081

Part Description: Not Available

Connector No: D2695A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Integrated Center Stack Switch Bank Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Integrated Center Stack Switch Bank Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

D434

0.35

DIAGNOSTIC CAN IHS (+)

N/A

R168

GY/DB

0.35

AIRBAG OFF LAMP PASSENGER

EXPORT

R167

GY/WH

0.35

AIRBAG ON LAMP PASSENGER

EXPORT

A108

0.5

FUSED B(+)

N/A

D433

0.35

DIAGNOSTIC CAN IHS (-)

N/A

Z406

BK/VT

0.35

GROUND

N/A

Z406

0.5

GROUND

N/A

L91

GN/RD

0.35

HAZARD SWITCH SENSE

N/A

⁽¹⁾	Pins not listed are not used for this connector
