Camera-Rear (Standard) Connector End View (D3130A)

Harness-Family: Tailgate

Color: BLACK

Gender: FEMALE

Part Number: 3FA1ENARJ-C01ER

Part Description: Not Available

Connector No: D3130A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Camera-Rear Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Camera-Rear Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

J220

0.82

COAX CABLE A LVDS CAMERA REAR SIG

N/A

⁽¹⁾	Pins not listed are not used for this connector
