Module-Body Control C2/B (Standard) Connector End View (D3806B)

Harness-Family: Dash

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 7283-6469-40

Part Description: Not Available

Connector No: D3806B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Body Control C2/b Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Body Control C2/b Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z906

BK/GY

1.0

GROUND

N/A

A904

VT/RD

3.0

FUSED B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
