Module-Drive Train Control C3 (Standard) Connector End View (D3872C)

Harness-Family: Body

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 15466671

Part Description: Not Available

Connector No: D3872C

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Drive Train Control C3 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Drive Train Control C3 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A194

RD/GY

2.5

FUSED B(+)

N/A

Z916

BK/YE

2.5

GROUND

N/A

T316

YE/GY

2.5

SHIFT MOTOR CONTROL B

EXPORT

T315

YE/BN

2.5

SHIFT MOTOR CONTROL A

EXPORT

⁽¹⁾	Pins not listed are not used for this connector
