Module-Emergency Assistance C2 (Standard) Connector End View (D3115B)

Harness-Family: Antenna_IP

Color: BLUE

Gender: FEMALE

Part Number: 2035141-3

Part Description: Not Available

Connector No: D3115B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Emergency Assistance C2 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Emergency Assistance C2 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

J231

0.20

COAX - NAV GPS SIG

N/A

⁽¹⁾	Pins not listed are not used for this connector
