Module-Integrated Center Stack Switch Bank (Standard) Connector End View (D2695A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 30700-1081

Part Description: Not Available

Connector No: D2695A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Integrated Center Stack Switch Bank Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Integrated Center Stack Switch Bank Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

D463

0.75

CAN IHS (+)

N/A

A231

RD/OG

0.75

FUSED B(+)

N/A

D462

0.75

CAN IHS (-)

N/A

Z912

BK/OG

0.75

GROUND

N/A

L91

WH/DB

0.75

HAZARD SWITCH SENSE

N/A

⁽¹⁾	Pins not listed are not used for this connector
