Module-Steering Column-Lock (Standard) Connector End View (D3925A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 1-1534121-1_1534120-1

Part Description: Not Available

Connector No: D3925A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Steering Column-Lock Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Steering Column-Lock Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

B22

DG/GN

0.35

VEHICLE SPEED SIGNAL 1

N/A

F915

0.50

FUSED IGNITION RUN/START

N/A

Z911

BK/VT

0.50

GROUND

N/A

D253

YE/DG

0.35

CAN C (+)

N/A

D252

0.35

CAN C (-)

N/A

A230

RD/BN

0.50

FUSED B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
