Module-Tire Pressure (Standard) Connector End View (D3857A)

Harness-Family: Chassis_RT

Color: BLACK

Gender: FEMALE

Part Number: 1-967640-1

Part Description: Not Available

Connector No: D3857A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Tire Pressure Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Tire Pressure Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A943

0.50

FUSED B(+)

N/A

Z906

0.50

GROUND

N/A

D93

0.50

CAN C (+)

N/A

D94

0.50

CAN C (-)

N/A

⁽¹⁾	Pins not listed are not used for this connector
