Module-Headlamp Leveling (Standard) Connector End View (D2720A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 33472-1601

Part Description: Not Available

Connector No: D2720A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Headlamp Leveling Connector End View (Standard)
GCWD1006428Courtesy of CHRYSLER
Fig 2: Module-Headlamp Leveling Component Location (Standard)
GCWD1284783Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
2 L131 WH/GN 0.35 LEFT HEADLAMP LEVEL SENSOR SIGNAL N/A
3 D257 YE/VT 0.35 CAN C (+) N/A
4 L132 GN/WH 0.35 RIGHT HEADLAMP LEVEL SENSOR SIGNAL N/A
7 L966 WH/BK 0.35 HEADLAMP LEVELING SENSOR FRONT RETURN N/A
8 L960 WH/DG 0.35 HEADLAMP LEVELING SENSOR FRONT SIGNAL N/A
9 Z910 BK/GY 0.35 GROUND N/A
11 F927 PK/YE 0.50 FUSED IGNITION N/A
12 D256 YE 0.35 CAN C (-) N/A
15 F861 WH/PK 0.35 HEADLAMP LEVELING SNSR 5V SUPPLY N/A
16 L963 WH/DB 0.35 HEADLAMP LEVELING SENSOR REAR SIGNAL N/A
(1) Pins not listed are not used for this connector
