Module-Fuel Pump (Standard) Connector End View (D6602A)

Harness-Family: Chassis_RT

Color: BLACK

Gender: FEMALE

Part Number: 13521463

Part Description: Not Available

Connector No: D6602A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Fuel Pump Connector End View (Standard)
GCWD1013717Courtesy of CHRYSLER
Fig 2: Module-Fuel Pump Component Location (Standard)
GCWD1284772Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
A N14 VT/BU 2.0 FUEL PUMP RETURN N/A
B N4 DB/WH 1.0 FUEL LEVEL SENSOR SIGNAL N/A
C G109 BK 1.0 FUEL LEVEL SENSE RETURN N/A
D N13 DB/OG 2.0 FUEL PUMP PWM CONTROL N/A
(1) Pins not listed are not used for this connector
