Module-Light Rain Sensor (Standard) Connector End View (D2683A)

Harness-Family: MIRROR_INT_JMPR

Color: BLACK

Gender: FEMALE

Part Number: 1-1718346-1

Part Description: MQS 3P CONNECTOR

Connector No: D2683A

Option: Standard

Repair Kit Part Number: 68052579AA

Cavity Count: 3

Fig 1: Module-Light Rain Sensor Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Light Rain Sensor Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Module-Light Rain Sensor Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Module-Light Rain Sensor Component Location View (Standard)

Courtesy of CHRYSLER
